Switchgear serves as the backbone of medium and high voltage (MV/HV) power systems, performing three critical roles for transformers:

• ​Power Distribution: Routes electricity from transformers to loads via feeders, busbars, and protection devices.
• ​Fault Protection: Interrupts faults currents within milliseconds (e.g., 31.5kA–40kA short-circuit breaking capacity) to prevent equipment damage .
• ​Safety Isolation: Ensures safe maintenance through mechanical interlocks and grounding mechanisms.

For example, a 12kV system requires a minimum phase-to-ground clearance of 125mm (air-insulated) or 40mm (gas-insulated) to prevent arcing

.

​Detailed Analysis of M&H Voltage Power Electronic Transformer Types, Structural Configurations, and Key Parameters

The Neutral Point Clamped (NPC) multilevel topology is shown. Besides the diode-clamped NPC topology , NPC topologies also include flying capacitor type and hybrid clamped type, among others. However, due to the large capacitor volume, NPC topologies still mostly use passive or active switching devices for clamping. Taking the diode-clamped multilevel topology as an example, in a three-phase rectifier stage topology, each phase leg consists of cascaded switching transistors and clamping diodes, connected in parallel to a single high-voltage DC bus. Literature  proposed a single-phase PET topology with a rectifier stage using a four-level diode-clamped circuit. A single high-voltage DC bus is followed by input-series-output-parallel DABs, as shown . This topology can be expanded into a three-phase structure, and the number of voltage levels can be changed based on device withstand voltage levels and the high-voltage side voltage level. Like the MMC topology, the NPC topology can also be applied in the isolation stage, connecting the high-voltage DC bus to the isolation transformer, as shown. Literature applied a three-level diode-clamped NPC converter to the high-voltage side of an LLC resonant converter, verifying it on a 166kW/2kV~400V prototype. Literature applied a three-level diode-clamped NPC circuit to a three-phase DAB, achieving ideal DAB voltage and current characteristics.

PET topologies vary widely. Based on the number of energy conversion stages, they can be classified into single-stage, two-stage, and three-stage types [7]. Two-stage structures include those with high-voltage and low-voltage DC buses, as shown in Figure 1.

With the proposal of the energy internet concept and the widespread application of smart grid-related technologies, the proportion of renewable energy sources such as wind and photovoltaic power in the existing energy system will significantly increase. This indicates that future power grids will become more intelligent and flexible. In the energy internet, as the proportion of distributed users and energy resources rises, electricity transmission demands highly controllable capabilities. In smart distribution networks, the grid must maintain highly stable and high-quality power supply while compatibly integrating a large number of distributed renewable energy sources and monitoring/managing grid operational states. These requirements place stringent demands on the intelligence of energy grid equipment, whereas traditional power frequency transformers inherently face functional limitations.

A high-voltage transformer is an electrical device engineered to convert electrical energy between voltage levels, typically operating within the range of ​110 kV to 500 kV. These transformers are pivotal in power transmission systems, minimizing energy losses during long-distance transmission while ensuring safe delivery of electricity to households, businesses, and industries. For instance, power plants generate electricity at high voltages, and transformers adjust this voltage—either stepping it up for transmission or stepping it down for end-user consumption—to optimize efficiency and safety

.

JZP Transformer is a global leader in serving the renewable energy sector worldwide. With a proven track record, we have supplied thousands of transformers for photovoltaic and energy storage projects across North America, Europe, and Australia. Our products not only meet stringent standards such as IEEE, ANSI, CSA, AN, IEC, and BS,  but also hold certifications including UL, cUL, CSA, CE, SGS, and others, supported by comprehensive test reports.

Europe is at the forefront of the renewable energy transition, with wind and solar power playing a growing role in electricity generation. In addition to renewable sources, Europe also relies on nuclear and Combined Heat and Power (CHP) plants for stable electricity supply. JZP’s transformers help manage this complex mix of energy sources by ensuring effective voltage regulation and efficient grid connectivity.

The global transition to renewable energy—particularly wind and solar—has highlighted the critical need for efficient energy storage solutions. These technologies address the intermittency of renewables, ensuring grid stability and enabling seamless integration of decentralized power sources. Energy storage systems (ESS) mitigate production-demand mismatches, reduce reliance on fossil fuels, and support climate goals by curbing carbon emissions

As the world focuses on sustainability, the need for renewable energy solutions has become more vital than ever. Renewable power plants are at the forefront of this movement, utilizing various sources such as wind, solar, tidal, and geothermal energy to meet the increasing demand for clean energy. To ensure optimal use of these sources, well-designed power plants that can efficiently handle energy requirements are essential. One crucial element of such designs is incorporating transformers, which play a critical role in boosting voltage levels for long-distance power transmission, while also providing isolation and voltage regulation.
